BAJAJ DISCOVER
DTSi
Discover the Jaadoo
 Bajaj
Discover is a bike with all the latest features. It has ExhausTEC
tecnology, SNS suspension and a ride control switch. It comes in two
variants, the base model and Discover DTSi. The base model is of 112 cc
and the DTSi, 125 cc. The 112 cc gives the rider the best mileage of 101
kmpl (under standard test conditions). The DTSi is ranked among the most
powerful and torquey in the 125 cc class of bikes.
| Company |
Stroke |
Maximum Power |
Displacement |
| Bajaj
Auto Ltd. |
4-Stroke |
8.5 bhp (6.26 kW) @ 7500 rpm |
111.63 cc (124.52 cc Discover DTS-i) |
Striking Features
- Athletic, Lean and Muscular styling
- 101 kmpl ExhausTEC mileage
- Telescopic Front suspension of 30 mm diameter and the longest
travel in its class of 135 mm.
- World first SNS (Spring-N-Spring) Rear suspension with triple
rated springs, also the longest travel in its class of 110 mm.
Model Variants
- Bajaj Discover
- Bajaj Discover DTSi
Quotes-Unquotes
"Looking beyond the face, the fazer is
decidedly cool. Its tank is super, with dummy scoops, supremely compy
knee recesses and a dinky blower-hat tank lid. Blistered side panels
reverse and meet a rounded tail fairing."
Autocar magazine October 2004
"Serial killer with suave manners!"
Overdrive magazine September 2004 Technical Specifications
| Dimensions
|
| Length |
2030 mm |
| Width |
760 mm |
| Height |
1065 mm |
| Wheel base |
1305 mm |
| Turning circle dia |
2100 mm |
| Ground clearance |
179 mm |
| Kerb Weight |
125 kg – Kick start / 129 kg – Electric
start |
| Engine |
| Type |
4-Stroke, DTS-I, Natural Air Cooled |
| Displacement |
124.52 cc |
| Max Net Power |
16.5 bhp/ 12.15 kw @ 8000 rpm |
| Max Net Torque |
10.8 Nm @ 6500 rpm |
| Clutch |
Wet, Multidisc Type |
| Ignition system |
Microprocessor controlled Digital CDI |
| Starting system |
Kick Start / Self Start |
| Frame |
Double cradle tubular type |
| Suspension |
| Front Suspension |
Telescopic |
| Rear Suspension |
Trailing arm with coaxial hydraulic shock
absorbers & coil springs |
| Brakes |
| Front Brake |
Mechanical expanding shoe & drum type –
130 mm diameter |
| Rear Brake |
Mechanical expanding shoe & drum type –
130 mm diameter |
| Tyres |
| Front Tyre Size |
2.75 x 17, 4PR |
| Rear Tyre Size |
3.00 x 17, 6PR |
| Fuel Tank |
| Fuel Tank capacity |
10 Litres (2.3 litres for reserve) |
| Electricals |
| System Voltage |
12V (AC + DC) |
| Headlamp |
Electric start – 35/ 35W Optoprism- Halogen
lamp, Kick start – 60/55 W Round Headlamp |
| Battery type |
12V, 2.5 Ah(KS)/12 V, 9 Ah (ES) |
| Tail lamp |
5/21 W |
| Brake lamp |
10 W |
| Turn signal lamp |
10 W |
| Horn |
12 V, Dc |
